Welding Fume Extractor for Institutions
Welding Fume Extractor for Institutions
images Send Inquiry
Request To Call Back

Welding Fume Extractor for Institutions

Price 75000 INR/ Unit

Get a Price/Quote
MOQ : 1 Unit

Welding Fume Extractor for Institutions Specification

  • Temperature
  • Ambient operating: 5C to 45C
  • Scrubber Type
  • Dry type/cartridge filter
  • Instruments Type
  • Fume Extractor
  • Power Source
  • Electric
  • Display Type
  • Digital control panel
  • Air Flow
  • 800 m/h
  • Usage & Applications
  • Institutions, Laboratories, Workshops, Vocational education for welding fume extraction
  • Measurement
  • Particulate concentration
  • Orientation
  • Vertical
  • Efficiency
  • 99 % (for welding fume filtration)
  • Automation Grade
  • Semi-automatic
  • Sensor Type
  • Integrated aerosol sensor
  • Product Type
  • Welding Fume Extractor
  • Material
  • Mild Steel body
  • Cooling System
  • Air cooled
  • Noise Level
  • <70 dB
  • Reactor Thickness
  • 2 mm MS
  • Processing Time
  • Continuous
  • Capacity
  • 800 m/h
  • Voltage
  • 220V / 50Hz
  • Weight
  • 55 kg
  • Dimension (L*W*H)
  • 600 x 460 x 900 mm
  • Surface
  • Powder coated
  • Number of Filter Stages
  • Two-stage filtration
  • Filter Type
  • HEPA filter + carbon filter
  • Installation Type
  • Portable/Floor-mounted
  • Mobility
  • Castor wheels for easy movement
  • Cleaning Method
  • Manual cleaning of filter
  • Exhaust Hose Length
  • 2 meters flexible hose
  • Extraction Arm
  • Flexible, rotatable with hood
  • Fan Motor Power
  • 0.75 kW
  • Input Power
  • 1 kW
  • Safety Standard
  • Conforms to ISO 21904-1:2020
  • Protection Features
  • Overload and short-circuit protection


Welding Fume Extractor for Institutions Trade Information

  • Minimum Order Quantity
  • 1 Unit
  • Supply Ability
  • 1000 Units Per Day
  • Delivery Time
  • 1 Week
  • Main Domestic Market
  • South India
  • Certifications
  • ISO 9001:2008


About Welding Fume Extractor for Institutions

We are the reputed manufacturer, exporter and supplier of excellent performing Fume Extractor Welding. The offered fume extractor is widely used for collecting the fume and other particles at the time of welding before it reaches to welders breathing zone in various industries. It is manufactured in our highly advanced production unit using premium quality components and cutting-edge technologies. The provided Fume Extractor Welding is also checked on various quality parameters to ensure its flawless functionality.

Features:

  • Safe disposal of collected fume
  • Low power consumption
  • Hassle-free functionality
  • Low power consumption


Dual-Stage Filtration for Clean Air

Equipped with both HEPA and carbon filters, this fume extractor ensures two-stage particle and gas filtration with an efficiency of at least 99%, vital for institutional environments where safety and air quality are paramount. The dry-type cartridge filter minimizes maintenance and maximizes operational uptime.


User-Friendly and Portable Design

Thanks to its castor wheels and compact vertical form factor, the extractor can be easily relocated within laboratories, workshops, or classrooms. The flexible, rotatable extraction arm and 2-meter hose enable precise targeting of welding fumes, enhancing function and ease of use for various applications.


Safety First, Reliable Performance

Meeting ISO 21904-1:2020 standards, the system includes overload and short-circuit protection, ensuring safe operation. Its rugged mild steel body and powder coated finish guarantee durability, while manual filter cleaning and integrated digital controls provide practical maintenance and monitoring options for continuous workflow.

FAQs of Welding Fume Extractor for Institutions:


Q: How does the welding fume extractor operate in institutional settings?

A: This portable unit uses a two-stage filtration processHEPA and carbon filtersto remove welding fumes. Its castor wheels and vertical orientation ensure it can be easily moved between workstations in laboratories, workshops, or vocational classrooms.

Q: What maintenance procedure is required for the filter system?

A: Filters are cleaned manually. Regular filter maintenance is recommended to sustain optimal performance and filtration efficiency, typically assessed via the digital control panel and aerosol sensor readings.

Q: When should the extractor be used during welding activities?

A: It should be operated continuously whenever welding work is performed to maintain safe air quality and minimize health risks from fume exposure. The extractors high airflow rate delivers efficient real-time fume control.

Q: Where is the best location for installing the fume extractor?

A: The extractor can be floor-mounted or simply stationed on a level surface near welding workstations, thanks to its mobility. Placement should allow easy access for the flexible arm and ensure proper coverage of the welding process area.

Q: Which protection features enhance operational safety?

A: Safety is ensured with overload and short-circuit protection, adherence to ISO 21904-1:2020 standards, and a mild steel body with powder coating. The built-in digital control panel also enables convenient system monitoring.

Q: What benefits does the HEPA and carbon filter combination provide?

A: The HEPA filter captures fine particulates while the carbon filter adsorbs gaseous contaminants, making the air cleaner and safer. This dual-stage system is especially effective in environments with frequent welding operations.

Q: How can users monitor performance and ensure efficient operation?

A: The integrated digital control panel displays system status, filter condition, and particulate concentration as measured by the aerosol sensor, helping users make timely maintenance decisions and ensure efficient fume extraction.

Welding Fume Extractor for Institutions
Tell us about your requirement
product

Price:

Quantity
Select Unit

  • 50
  • 100
  • 200
  • 250
  • 500
  • 1000+
Additional detail
Mobile number

Email

More Products in Fume Extractor Category

Tig Welding Fume Extractor
